GreenLine portable emissions analyzers have the following features as detailed in the CHART below:

  • Efficiency
  • Stack Gas Temperature
  • Air Temperature
  • Excess Air
  • Draft
  • O2
  • CO
  • CO2
  • NO
  • NO2
  • Low NOx
  • SO2
  • CxHy Hydrocarbons
  • H2S
  • Gas Velocity
  • Built-In Printer
  • Built-In Chiller
  • Heated Line
  • NDIR Bench
  • Automatic CO Sensor Protection
  • Internal Memory
  • Windows Compatible Software
GreenLine 2000 GreenLine 4000 GreenLine 6000 GreenLine 8000
Maximum Number of Sensors 2 4 6 9
Intermal Memory
(Samples Stored)		 250 250 1000 9000
Draft/Differential Pressure Optional Optional Standard Standard
Gas Velocity   Optional Optional Optional
Built-In Printer
(Non-Thermal)		 Optional Optional Standard Standard
Automatic CO Sensor Protection   Standard Standard Standard

O2 Sensor
(0-25%)		 Standard Standard Standard Standard
CO Sensor
(0-8000ppm)		 Optional Standard Standard Standard
CO Sensor
(0-20,000ppm)		   Optional Optional Optional
CO Sensor
(0-10%)		   Optional Optional Optional
CO2 Calculated
(0-99.9%)		 Standard Standard Standard Standard

NO Sensor
(0-4000ppm)		 Optional Optional Optional Standard
Low NO Sensor
(0-500ppm)		   Optional Optional Optional
NO2 Sensor
(0-1000ppm)		   Optional Optional Optional
Low NO2 Sensor
(0-100ppm)		   Optional Optional Optional

SO2 Sensor
(0-4000ppm)		   Optional Optional Optional
Low SO2 Sensor
(0-500ppm)		   Optional Optional Optional
CxHy Sensor
(0-5%)		   Optional Optional Optional
H2S Sensor
(0-1000ppm)		     Optional Optional

CO2 NDIR Sensor
(0-40%)		       Optional
CO NDIR Sensor
(0-2500ppm)		       Optional
CO NDIR Sensor
(0-15%)		       Optional
CxHy NDIR Sensor
(0-50,000ppm)		       Optional
Built-In Peltier Chiller     Optional Standard
Heated Hose & Heated Probe       Optional
Bluetooth Wireless Communication
for Remote Control/Display		       Standard
GreenLine 2000 GreenLine 4000 GreenLine 6000 GreenLine 8000


**All GreenLine analyzers come standard with ability to measure gas and air temperature, and calculate efficiency and excess air.
